0102391 AIR SUPPLY Replacement Part

0102391 is an AIR SUPPLY compressor part number. In the Compressor Parts Finder database, AIR SUPPLY 0102391 cross-references to OCP OS280-001, an air/oil separator, fitted to 8 listed compressor models.

AIR SUPPLY 0102391 cross-reference details

OCP OS280-001 — replacement part for AIR SUPPLY 0102391
Brand
AIR SUPPLY
Searched part number
0102391
Matched part number
0102391
OCP replacement SKU
OS280-001
Keltec / alternative SKU
KV280-001
Product type
Air/Oil Separator

Compressor models this part fits

AIR SUPPLY 0102391 / OCP OS280-001 is listed for the following compressors.

Technical specifications

Dimensions and media data for the OCP replacement of AIR SUPPLY 0102391.

D1 outer diameter
168 mm (6.61 in)
D2 diameter
300 mm (11.81 in)
D3 diameter
109 mm (4.29 in)
H1 height
497 mm (19.57 in)
H2 height
485 mm (19.09 in)
Flow
7.7 Nm³/min
Residual oil content
3 ppm
Media construction
Wrapped
Media material
Fiberglass
Service life *
4000 h

* Estimated figure for a complete service: air filter, separator, valves and the matching OCP lubricant (OCP 4000 = 4,000 h).

This part also replaces

The same OCP replacement covers these OEM codes as well as AIR SUPPLY 0102391.

← All AIR SUPPLY part numbers
