2901021300 ATLAS COPCO Replacement Part

2901021300 is an ATLAS COPCO compressor part number. In the Compressor Parts Finder database, ATLAS COPCO 2901021300 cross-references to OCP OS100-023, an air/oil separator, fitted to 11 listed compressor models.

Also written as 2901 0213 00, 2901-0213-00 and 2901.0213.00.

ATLAS COPCO 2901021300 cross-reference details

OCP OS100-023 — replacement part for ATLAS COPCO 2901021300
Brand
ATLAS COPCO
Searched part number
2901021300
Matched part number
2901021300
OCP replacement SKU
OS100-023
Keltec / alternative SKU
KV100-023
Product type
Air/Oil Separator

Compressor models this part fits

ATLAS COPCO 2901021300 / OCP OS100-023 is listed for the following compressors.

Technical specifications

Dimensions and media data for the OCP replacement of ATLAS COPCO 2901021300.

D1 outer diameter
168 mm (6.61 in)
D2 diameter
300 mm (11.81 in)
D3 diameter
109.5 mm (4.31 in)
H1 height
230 mm (9.06 in)
Flow
7.2 Nm³/min
Residual oil content
3 ppm
Media construction
Wrapped
Media material
Fiberglass
Service life *
4000 h
GTIN
8721606860141

* Estimated figure for a complete service: air filter, separator, valves and the matching OCP lubricant (OCP 4000 = 4,000 h).

This part also replaces

The same OCP replacement covers these OEM codes as well as ATLAS COPCO 2901021300.
