3003104168 EDMAC Replacement Part
3003104168 is an EDMAC compressor part number. In the Compressor Parts Finder database, EDMAC 3003104168 cross-references to OCP OS1130-007P, an air/oil separator, fitted to 8 listed compressor models.
EDMAC 3003104168 cross-reference details
- Brand
- EDMAC
- Searched part number
- 3003104168
- Matched part number
- 3003104168
- OCP replacement SKU
- OS1130-007P
- Keltec / alternative SKU
- KV1130-007P
- Product type
- Air/Oil Separator
Compressor models this part fits
EDMAC 3003104168 / OCP OS1130-007P is listed for the following compressors.
- SULLAIR—RSVS25
- SULLAIR—RSVS32
- SULLAIR—TS32-400 / 1992>
- SULLAIR—TS32-500 / 1992>
- SULLAIR—TS32-600 / 1992>
- SULLAIR—VS25 USA VACCUM PUMP
- SULLAIR—VS32-150 USA VACCUM PUMP / 150 HP
- SULLAIR—VS32-200 USA VACUUM PUMP / 200 HP
Technical specifications
Dimensions and media data for the OCP replacement of EDMAC 3003104168.
- D1 outer diameter
- 276 mm (10.87 in)
- D2 diameter
- 590 mm (23.23 in)
- D3 diameter
- 189 mm (7.44 in)
- H1 height
- 678 mm (26.69 in)
- H2 height
- 676 mm (26.61 in)
- G1 thread
- 1/4" NPT
- Media construction
- Pleated
- Media material
- Fiberglass
This part also replaces
The same OCP replacement covers these OEM codes as well as EDMAC 3003104168.
