3003115168 EDMAC Replacement Part
3003115168 is an EDMAC compressor part number. In the Compressor Parts Finder database, EDMAC 3003115168 cross-references to OCP OS1000-066, an air/oil separator, fitted to 15 listed compressor models.
EDMAC 3003115168 cross-reference details
- Brand
- EDMAC
- Searched part number
- 3003115168
- Matched part number
- 3003115168
- OCP replacement SKU
- OS1000-066
- Keltec / alternative SKU
- KV1000-066
- Product type
- Air/Oil Separator
Compressor models this part fits
EDMAC 3003115168 / OCP OS1000-066 is listed for the following compressors.
- INGERSOLL RAND—R110I / 18305391> / 150 HP / Jan-10>
- INGERSOLL RAND—R110I / 80445828> / 150 HP / Jan-10>
- INGERSOLL RAND—R110N,IE / 150 HP / 80445828 / 2010
- INGERSOLL RAND—R132I / 18307009> / 175 HP
- INGERSOLL RAND—R150I / 200 HP / Jan-10>
- INGERSOLL RAND—R160I / 18307009> / 225 HP
- INGERSOLL RAND—R160I A110 A125 B03823> / 225 HP
- INGERSOLL RAND—R90I / 80445828> / 125 HP / Jan-10>
- INGERSOLL RAND—R90N,IE / 125 HP / 80445828 / 2010
- INGERSOLL RAND—RS110IE / 150HP / 2019>
- INGERSOLL RAND—RS132I / 175HP / 2019>
- INGERSOLL RAND—RS132IE / 175HP / 2019>
- INGERSOLL RAND—RS160I / 220HP / 2019>
- INGERSOLL RAND—RS160IE / 220HP / 2019>
- INGERSOLL RAND—RS90IE / 125HP / 2019>
Technical specifications
Dimensions and media data for the OCP replacement of EDMAC 3003115168.
- D1 outer diameter
- 298 mm (11.73 in)
- D2 diameter
- 381 mm (10.83 in)
- D3 diameter
- 222 mm (8.74 in)
- H1 height
- 450 mm (17.72 in)
- GTIN
- 8721606860196
This part also replaces
The same OCP replacement covers these OEM codes as well as EDMAC 3003115168.
